Canopy Mini Pureline 826

Type number: 826

Canopy Mini Pureline 826 Comparer
826 Canopy Novy Mini Pureline 90 cm
826 Canopy Novy Mini Pureline 90 cm
Timeless elegance

Mini Pureline 90 cm Mineral Black

  • Mineral Black: stylish design effect, low-maintenance and less sensitive to fingerprints
  • Integrated in a decorative chimney or alcove
  • Flexible installation of the Cubic motor for more placement options
  • Integrated dimmable LED lighting
  • LED lighting warm white (2700K) adjustable to neutral white (4000K)
Ecosmart Cooker hoods with a motor (direct outlet) Remote control InTouch Cubic Motor Peripheral extraction Click-and-fix Installation height 85cm

Optional

Recirculation
See other versions of this product

Specifications

Energy label

Energy Efficiency class (EEIhood)
A+
Annual Energy Consumption (kWh/year) (AEChood)
33,8
Lighting Efficiency class (LEhood)
A
Fluid Dynamic Efficiency class (FDEhood)
A
Grease Filtering Efficiency class (GFEhood)
D

Functions and features

Control method
Push buttons / Remote control
Number of speeds
3 + power
Automatic Power revert (minutes)
6
Motor
Integrated
Sound absorber
Integrated
Recirculation
Optional
InTouch function
Standard
Auto stop
Yes
Delayed switch off (minutes)
10
Number of grease filters
1
Grease filter
7400020
Grease filter cleaning indication
Yes
Recirculation filter cleaning indication
Yes
Novy Connect
Not applicable

Lighting

Functional lighting type
LED
Ambient lighting type
Not Applicable
Functional light dimmable
Yes
Soft-ON/OFF
Yes
Number of functional lights
4
Total energy consumption functional light (W)
8
Color functional light (K)
2700/4000
Color ambient light (K)
Not Applicable

Dimensions

Product dimensions (WxDxH) (mm)
860 x 301 x 330
Width flange (mm)
10
Dimensions cut-out opening (WxD) (mm)
845 x 286
Advised mounting height induction hobs (Hmin-Hmax) (mm)
650 - 850
Min dimensions cabinet (WxDxH) (mm)
x 600 x
Advised mounting height ceramic hobs (Hmin-Hmax) (mm)
600 - 850
Advised mounting height gas hobs (Hmin-Hmax) (mm)
650 - 850
Diameter outlet (mm)
150
Position exhaust
Right / Top / Left / Back / Front

Airflow and noise level

Airflow duct out speed 1 (m³/h)
237
Airflow duct out speed 2 (m³/h)
379
Airflow duct out speed 3 (m³/h)
451
Airflow duct out max powerspeed (m³/h) (Qboost)
601
Sound pressure duct out speed 1 (dB(A))
26
Sound pressure duct out speed 2 (dB(A))
36
Sound pressure duct out speed 3 (dB(A))
40
Sound pressure duct out at max powerspeed (dB(A))
47

Technical specifications

Maximum power (W)
121
Voltage appliance (V)
220-240
Frequency (Hz)
50-60
Length power supply cable (m)
1,3
Power consumption in stand-by-mode (Ps) (W)
0.25
Net weight (kg)
11,9
See all specifications

Manuals & downloads

Energy label Product File Technical File User Manual Installation Manual Declaration of conformity CAT Technical drawing Safety Instructions
