Venting hob Novy Panorama Power 90 cm
Type number: 1841
1841 Venting hob Novy Panorama Power 90 cm Black
- Direct extraction at source, thanks to the adjustable height: 10 cm, 20 cm, 30 cm
- preset auto-function
- semi-transparent extraction tower disappears invisibly into the hob
- 4 cooking zones + practical functions
- discrete and elegant design
- easy to maintain
Specifications
Weights & Dimensions
Product Depth
160 Millimetre
Product Width
821 Millimetre
Product Height
760 Millimetre
Product Weight (kg)
50 Kilogram
Product Dimensions (WxDxH) (mm)
821 Millimeter X 160 Millimeter X 760 Millimeter
Energy Specifications
Electrical Volts
230-400V
Electrical Total Wattage
7650 Watt
Length power supply cable
1.2 Metre
Electrical frequency
50-60 Hertz
Electrical Connection (Plug) Type
Schuko
Electrical Connection Location
Left
Maximum power spare part (W)
250
Installation Details
Position exhaust (to be delete)
Centraal onderaan
Functions and Features
Flexzone
1
Auto stop
Yes
Chef function
No
Grill function
No
Stop & Go function
No
Sound absorber
Integrated
Childproof lock
Yes
Number of Motors
2
Automatic Power revert (minutes)
6 Minute
Pot move function
No
Delayed switch off
Yes
Fan Motor Location
Integrated
Number of Fan Speeds
5 + 3
Grease filter
1821510,1821515
Safety time-switch-off
Yes
Number of Grease Filters
2
Automatic pan recognition
No
Diameter outlet
222x89
Grease filter cleaning indication
Yes
Recirculation filter cleaning indication
Yes
Timer Type
Timer, timer per zone
Control Type
Electronic
Recirculation
Optional
Control method
Touch control
Finishing
Glass
Residual heat indication in worktop
Yes
Delayed Switch Off Minutes
30, 10
Flexzone activation
Manual
Tower height (cm)
10, 20, 30
Regulation, Compliance, Certifications
Sound regulation
DIN 45625-2
Airflow duct out max powerspeed (m³/h) (Qboost)
691 Cubic meter per hour
Airflow duct out at min speed (m3/h) (Qmin)
193 Cubic meter per hour
Airflow at best efficiency point (QBEP) (m³/h)
345.6 Cubic meter per hour
Sound pressure duct out at minimum speed
27 dB(A)
Sound pressure duct out at max powerspeed
56 dB(A)
Sound power duct out at max continuous speed (dB(A))
57 dB(A)
Airflow duct out at max continuous speed (Qmax)
475 Cubic meter per hour
Sound pressure duct out at max continuous speed
46 dB(A)
Annual Energy Consumption (AEChood)
50,5
Energy efficiency class (EEIhood)
B
Fluid dynamic efficiency class (FDEhood)
B
Grease filtering efficiency class (GFEhood)
C
Additional Technical Specifications
Super Power function
Yes
Wipeguard function
No
Main on/off switch
No
Exterior Finish Color
Black
Number of Cooking Zones
4 zones
Depth backside cut out opening (mm)
38 Millimetre
Voltage cooker hood (V)
230
Cooking Surface Configuration
| Cooking zone | Position | Zone Dimension (mm) | Cooking zone type | Power Rating | Power Rating (Power) |
|---|---|---|---|---|---|
| Cooking zone 1 | Left | 185 | Induction cooking zone | 1400 Watt | |
| Cooking zone 2 | Left Center | 210 | Induction cooking zone | 2300 Watt | 3000 Watt |
| Cooking zone 3 | Right Center | 200x240 | Induction cooking zone | 2100 Watt | 3000 Watt |
| Cooking zone 4 | Right | 200x240 | Induction cooking zone | 1600 Watt | 1850 Watt |
Cleaning products
906091, 906092, 906093
Window switch
990036
Recirculation box
7921400, 7922400, 7923400
Recirculation filter
7910055
