Venting hob Novy Easy Prestige 90 cm
Type number: 1866
1866 Venting hob Novy Easy Prestige 90 cm Black
- Elegant black powder-coated aluminium rotary control knobs
- One reference for recirculation and duct out
- Extra large cooking surface
- Optimised airflow due to elegant finish
- 4 cooking zones and useful functions
- Surface and flush installation possible
£ 4,799 including VAT
Specifications
Weights & Dimensions
Product Depth
520 Millimetre
Product Width
900 Millimetre
Product Height
215 Millimetre
Product Weight
23.5 Kilogram
Width
90 cm
Product Dimensions (WxDxH) (mm)
900 MILLIMETER X 520 MILLIMETER X 215 MILLIMETER mm
Energy Specifications
Electrical Volts
230-400V
Electrical Connection (Plug) Type
Other
Electrical Total Wattage
7568 Watt
Length power supply cable
1.5 Metre
Electrical frequency
50-60 Hertz
Electrical Connection Location
Right
Installation Details
Position exhaust
Left rear
Functions and Features
Flexzone
2
Auto stop
Timer Type
Automatic pre-cooking
Control type
Touch control
Chef function
Recirculation
Monoblock, Standard
Control method
Rotary knob
Grill function
Stop & Go function
Childproof lock
Number of Motors
1
Automatic Power revert (minutes)
10 Minute
Pot move function
Delayed switch off
Info display color
Red
Fan Motor Location
Integrated
Keep Warm Function
42°C
Number of Fan Speeds
9 + power
Exterior Finish Colour
Black
Grease filter
99003
Functioning mode
Duct out & recirculation
Safety time-switch-off
Finishing
Glossy glass
Number of Grease Filters
1
Residual heat indication in worktop
Yes
Automatic pan recognition
Diameter outlet
222x89
Delayed Switch Off Minutes
30
Flexzone activation
Manual
Grease filter cleaning indication
Recirculation filter cleaning indication
Regulation, Compliance, Certifications
Airflow duct out speed 1
220 Cubic meter per hour
Annual Energy Consumption (AEChood)
17,9
Time increase factor (f)
0.60
Sound power duct out speed 1
46 dB(A)
Max pressure duct out speed 1
46 Pascal
Max pressure duct out speed 4 (Pa)
452 Pascal
Sound regulation
DIN 45625-2
Sound pressure duct out speed 1
34 dB(A)
Energy efficiency class (EEIhood)
A+++
Airflow duct out max powerspeed (Qboost)
610 Cubic meter per hour
Max pressure duct out at minimum speed
46 Pascal
Lighting efficiency class (LEhood)
Niet van toepassing
Sound power duct out at minimum speed (LWAmin)
46 dB(A)
Airflow duct out at min speed (Qmin)
220 Cubic meter per hour
Max pressure duct out at maximum powerspeed
452 Pascal
Airflow at best efficiency point (QBEP)
288.1 Cubic meter per hour
Sound pressure duct out at minimum speed
34 dB(A)
Fluid dynamic efficiency class (FDEhood)
A
Sound power duct out at max powerspeed (LWAboost)
70 dB(A)
Sound pressure duct out at max powerspeed
58 dB(A)
Sound power duct out at max continuous speed (LWAmax)
66 dB(A)
Grease filtering efficiency class (GFEhood)
B
Max pressure duct out at max continuous speed
263 Pascal
Airflow duct out at max continuous speed (Qmax)
520 Cubic meter per hour
Sound pressure duct out at max continuous speed
54 dB(A)
Additional Technical Specifications
Glass edge
Rounded border
Cleaning products
906091, 906092, 906093
Lighting
710101-p3,710102-p3,710201-p3,710202-p3,740101,740102,740201,740202
Wipeguard function
Main on/off switch
Free airflow
750 Cubic meter per hour
Number of Cooking Zones
4 zones
Recirculation kit
1861820
Cut-out worktop (WxD) (mm)
750 x 490
Cooking accessories
1700092, 1700093, 1700095, 1700099, 1700100
Depth backside cut out opening
55 Millimetre
Voltage cooker hood (V)
230
Cooking Surface Configuration
| Cooking zone | Position | Zone Dimension (mm) | Cooking zone type | Power Rating | Power Rating (Power) |
|---|---|---|---|---|---|
| Cooking zone 1 | Left Front | 240x210 | Induction cooking zone | 2100 Watt | 3000 Watt |
| Cooking zone 2 | Left Rear | 240x210 | Induction cooking zone | 2100 Watt | 3000 Watt |
| Cooking zone 3 | Right Rear | 240x210 | Induction cooking zone | 2100 Watt | 3000 Watt |
| Cooking zone 4 | Right Front | 240x210 | Induction cooking zone | 2100 Watt | 3000 Watt |
