Venting hob Novy Panorama Power 90 cm
Type number: 1831
1831 Venting hob Novy Panorama Power 90 cm Black
- Direct extraction at source, thanks to the adjustable height: 10 cm, 20 cm, 30 cm
- preset auto-function
- semi-transparent extraction tower disappears invisibly into the hob
- 3 cooking zones + practical functions
- discrete and elegant design
- easy to maintain
£ 4,214 including VAT
Specifications
Weights & Dimensions
Product Depth
520 Millimetre
Product Width
880 Millimetre
Product Height
65 Millimetre
Product Weight
50 Kilogram
Width
90 cm
Product Dimensions (WxDxH) (mm)
880 MILLIMETER X 520 MILLIMETER X 65 MILLIMETER mm
Energy Specifications
Electrical Volts
230-400V
Electrical Connection (Plug) Type
Schuko
Electrical Total Wattage
6950 Watt
Maximum power cooker hood
250 Watt
Length power supply cable
1.2 Metre
Electrical frequency
50-60 Hertz
Maximum power induction hob
6700 Watt
Electrical Connection Location
Left
Maximum power spare part (W)
250
Installation Details
Position exhaust
Center bottom
Functions and Features
Flexzone
1
Auto stop
Timer Type
Timer per zone, timer
Control type
Electronic
Novy Connect
Standard
Chef function
Recirculation
Default setting
Control method
Touch control
Grill function
Stop & Go function
Sound absorber
Integrated
Childproof lock
Number of Motors
2
Automatic Power revert (minutes)
6 Minute
Pot move function
Delayed switch off
Info display color
Red
Fan Motor Location
Integrated
Number of Fan Speeds
5 + 3
Exterior Finish Colour
Black
Grease filter
1821510,1821515
Functioning mode
Duct out & recirculation
Safety time-switch-off
Finishing
Glossy glass
Number of Grease Filters
2
Residual heat indication in worktop
Yes
Automatic pan recognition
Diameter outlet
222x89
Delayed Switch Off Minutes
30, 10
Flexzone activation
Manual
Tower height (cm)
Freely adjustable (10-30)
Grease filter cleaning indication
Recirculation filter cleaning indication
Regulation, Compliance, Certifications
Annual Energy Consumption (AEChood)
50,5
Time increase factor (f)
1.10
Max pressure duct out speed 1
40 Pascal
Energy efficiency class (EEIhood)
B
Airflow duct out max powerspeed (Qboost)
691 Cubic meter per hour
Max pressure duct out at minimum speed
40 Pascal
Sound power duct out at minimum speed (LWAmin)
37 dB(A)
Airflow duct out at min speed (Qmin)
193 Cubic meter per hour
Max pressure duct out at maximum powerspeed
437 Pascal
Airflow at best efficiency point (QBEP)
345.6 Cubic meter per hour
Sound pressure duct out at minimum speed
27 dB(A)
Fluid dynamic efficiency class (FDEhood)
B
Sound power duct out at max powerspeed (LWAboost)
65 dB(A)
Sound pressure duct out at max powerspeed
56 dB(A)
Sound power duct out at max continuous speed (LWAmax)
57 dB(A)
Grease filtering efficiency class (GFEhood)
C
Max pressure duct out at max continuous speed
204 Pascal
Airflow duct out at max continuous speed (Qmax)
475 Cubic meter per hour
Sound pressure duct out at max continuous speed
46 dB(A)
Additional Technical Specifications
Glass edge
Rounded border
Cleaning products
906091, 906092, 906093
Lighting
710101-p3,710102-p3,710201-p3,710202-p3,740101,740102,740201,740202
Wipeguard function
Main on/off switch
Window switch
990036
Free airflow
1160 Cubic meter per hour
Number of Cooking Zones
3 zones
Recirculation box
7921400, 7922400, 7923400
Cut-out worktop (WxD) (mm)
860 x 500
Cooking accessories
1700092, 1700093, 1700095, 1700099, 1700100
Recirculation filter
7910055
Depth backside cut out opening
38 Millimetre
Voltage cooker hood (V)
230
Dimensions cooker hood (WxDxH) (mm)
818 × 165 × 760–840
Additional accessories
1821400
Cooking Surface Configuration
| Cooking zone | Position | Zone Dimension (mm) | Cooking zone type | Power Rating | Power Rating (Power) |
|---|---|---|---|---|---|
| Cooking zone 1 | Left | 280 | Induction cooking zone | 2300 Watt | 3000 Watt |
| Cooking zone 2 | Center | 200x240 | Induction cooking zone | 2100 Watt | 3000 Watt |
| Cooking zone 3 | Right | 200x240 | Induction cooking zone | 1600 Watt | 1850 Watt |
