Built-in cooker hood Novy Mini Pureline 120 cm
Type number: 866
866 Built-in cooker hood Novy Mini Pureline 120 cm Mineral Black
- Mineral Black: stylish design effect, low-maintenance and less sensitive to fingerprints
- Integrated in a decorative chimney or alcove
- Flexible installation of the Cubic motor for more placement options
- Integrated dimmable LED lighting
- LED lighting warm white (2700K) adjustable to neutral white (4000K)
Specifications
Weights & Dimensions
Product Depth
301 Millimetre
Product Width
1160 Millimetre
Product Height
330 Millimetre
Product Weight (kg)
13 Kilogram
Width
120 cm
Product Dimensions (WxDxH)
1160 Millimeter X 301 Millimeter X 330 Millimeter
Energy Specifications
Electrical Volts
220-240V
Electrical Total Wattage
121 Watt
Fuse (A)
10
Length power supply cable
1.3 Metre
Electrical frequency
50-60 Hertz
Electrical Connection (Plug) Type
Schuko
Electrical Connection Location
Top, Right
Installation Details
Diameter duct
150 Millimetre
Max mounting height gas hobs
950 Millimetre
Min mounting height gas hobs
650 Millimetre
Max mounting height ceramic hobs
950 Millimetre
Min mounting height ceramic hobs
600 Millimetre
Max mounting height induction hobs
950 Millimetre
Min mounting height induction hobs
650 Millimetre
Width flange (mm)
10
Position exhaust (to be delete)
Rechts Boven Links Achter Voor
Installation Type
Built-in appliance
Depth cut out opening (mm)
286
Width cut out opening (mm)
1145
Dimensions cut-out opening (WxD) (mm)
1145 x 286
Advised mounting height gas hobs (Hmin-Hmax) (mm)
650 - 950
Advised mounting height above ceramic hobs (Hmin-Hmax) (mm)
600 -950
Advised mounting height induction hobs (Hmin-Hmax) (mm)
650 - 950
Functions and Features
Auto stop
Yes
Novy Connect
Not applicable
Sound absorber
Integrated
InTouch function
Standard
Number of Motors
1
Automatic Power revert (minutes)
6 Minute
Delayed switch off
Yes
Fan Motor Location
Integrated
Automatic operation
No
Number of Fan Speeds
3 + power
Perimeter extraction
Yes
Grease filter
7400020
Number of Grease Filters
1
Diameter outlet
150
Grease filter cleaning indication
Yes
Recirculation filter cleaning indication
Yes
Control Type
Electronic
Recirculation
Optional
Control method
Remote control, Push buttons
Info display color
Green, Red
Functioning mode
Duct out
Finishing
Textured paint
Delayed Switch Off Minutes
10
Regulation, Compliance, Certifications
Airflow duct out speed 1 (m³/h)
245.4 Cubic meter per hour
Airflow duct out speed 2 (m³/h)
388.5 Cubic meter per hour
Airflow duct out speed 3 (m³/h)
464.8 Cubic meter per hour
Time increase factor (f)
0.70
Sound power duct out speed 1
39 dB(A)
Sound power duct out speed 2
49 dB(A)
Sound power duct out speed 3
53 dB(A)
Max pressure duct out speed 1
82 Pascal
Max pressure duct out speed 2
226 Pascal
Max pressure duct out speed 3
324 Pascal
Sound regulation
EN 60704-2-13
Sound pressure duct out speed 1
27 dB(A)
Sound pressure duct out speed 2
37 dB(A)
Sound pressure duct out speed 3
41 dB(A)
Nominal power of lighting system (WL)
11.5 Watt
Airflow duct out max powerspeed (Qboost)
614.9 Cubic meter per hour
Max pressure duct out at minimum speed
82 Pascal
Airflow duct out at min speed (Qmin)
245.4 Cubic meter per hour
Airflow at best efficiency point (QBEP)
334.9 Cubic meter per hour
Sound pressure duct out at minimum speed
27 dB(A)
Sound pressure duct out at max powerspeed
47 dB(A)
Sound power duct out at max continuous speed (LWAmax)
53 dB(A)
Max pressure duct out at max continuous speed
324 Pascal
Airflow duct out at max continuous speed (Qmax)
464.8 Cubic meter per hour
Sound pressure duct out at max continuous speed
41 dB(A)
Average illumination of the lighting system on the cooking surface (Emiddle)
376 Lux
Annual Energy Consumption (AEChood)
34
Energy efficiency class (EEIhood)
A+
Lighting efficiency class (LEhood)
A
Lighting efficiency index (LEhood)
32.7
Fluid dynamic efficiency class (FDEhood)
A
Grease filtering efficiency class (GFEhood)
E
Additional Technical Specifications
Exterior Finish Color
Mineral Black
Free airflow (m³/h)
815 Cubic meter per hour
Dissociated motor
800996
Cleaning products
906060, 906091, 906092, 906093
Control kit
990030
Window switch
990033
One-way valve
906271, 906432
Remote control
840029
Recirculation box
841400, 842400, 843400, 7931400, 7932400, 7933400
Recirculation kit
820400
Recirculation filter
830055, 7300055, 7900055
