Venting hob Novy Easy 65 cm
Type number: 1871
1871 Venting hob Novy Easy 65 cm Black
- Compact 65 cm downdraft for optimal space usage,
- perfect for installation in 60 cm kitchen cabinets
- Optimised airflow due to elegant finish
- Easy maintenance
- 4 cooking zones and useful functions
- Surface-mounting and flush-mounting possible
£ 2,599 including VAT
Specifications
Weights & Dimensions
Product Depth
520 Millimetre
Product Width
650 Millimetre
Product Height
248 Millimetre
Product Weight
15.8 Kilogram
Width
65 cm
Product Dimensions (WxDxH) (mm)
650 MILLIMETER X 520 MILLIMETER X 248 MILLIMETER mm
Energy Specifications
Electrical Volts
230-400V
Electrical Connection (Plug) Type
Other
Electrical Total Wattage
7568 Watt
Length power supply cable
2 Metre
Electrical frequency
50-60 Hertz
Electrical Connection Location
Right
Installation Details
Position exhaust
Left
Functions and Features
Flexzone
1
Auto stop
Timer Type
Timer, timer per zone, automatic cooking
Control type
Touch control
Chef function
Recirculation
Not applicable
Control method
Slider touch control
Grill function
Stop & Go function
Remote Control
Childproof lock
InTouch function
Not applicable
Number of Motors
1
Automatic Power revert (minutes)
10 Minute
Pot move function
Delayed switch off
Info display color
Red
Fan Motor Location
Integrated
Keep Warm Function
70°C
Number of Fan Speeds
9 + power
Exterior Finish Colour
Black
Grease filter
99005
Functioning mode
Duct out
Safety time-switch-off
Finishing
Glossy glass
Number of Grease Filters
1
Residual heat indication in worktop
Yes
Automatic pan recognition
Diameter outlet
222x89
Delayed Switch Off Minutes
10
Flexzone activation
Semi-automatic
Grease filter cleaning indication
Recirculation filter cleaning indication
Regulation, Compliance, Certifications
Airflow duct out speed 1
157 Cubic meter per hour
Annual Energy Consumption (AEChood)
18,2
Time increase factor (f)
0.60
Sound power duct out speed 1
41 dB(A)
Max pressure duct out speed 1
31 Pascal
Sound regulation
DIN 45625-2
Sound pressure duct out speed 1
29 dB(A)
Energy efficiency class (EEIhood)
A+++
Airflow duct out max powerspeed (Qboost)
571.7 Cubic meter per hour
Max pressure duct out at minimum speed
31 Pascal
Lighting efficiency class (LEhood)
Niet van toepassing
Sound power duct out at minimum speed (LWAmin)
41 dB(A)
Airflow duct out at min speed (Qmin)
157 Cubic meter per hour
Max pressure duct out at maximum powerspeed
481 Pascal
Airflow at best efficiency point (QBEP)
263.8 Cubic meter per hour
Sound pressure duct out at minimum speed
29 dB(A)
Fluid dynamic efficiency class (FDEhood)
A
Sound power duct out at max powerspeed (LWAboost)
73 dB(A)
Sound pressure duct out at max powerspeed
60 dB(A)
Sound power duct out at max continuous speed (LWAmax)
68 dB(A)
Grease filtering efficiency class (GFEhood)
B
Max pressure duct out at max continuous speed
308 Pascal
Airflow duct out at max continuous speed (Qmax)
487 Cubic meter per hour
Sound pressure duct out at max continuous speed
56 dB(A)
Additional Technical Specifications
Glass edge
Rounded border
Cleaning products
906091, 906092, 906093
Lighting
710101-p3,710102-p3,710201-p3,710202-p3,740101,740102,740201,740202
Wipeguard function
Main on/off switch
Free airflow
750 Cubic meter per hour
Number of Cooking Zones
4 zones
Cut-out worktop (WxD) (mm)
560x 490
Cooking accessories
1700088, 1700092, 1700093, 1700095, 1700099, 1700100
Depth backside cut out opening
55 Millimetre
Voltage cooker hood (V)
230
Cooking Surface Configuration
| Cooking zone | Position | Zone Dimension (mm) | Cooking zone type | Power Rating | Power Rating (Power) |
|---|---|---|---|---|---|
| Cooking zone 1 | Left Front | 210x220 | Induction cooking zone | 2100 Watt | 3000 Watt |
| Cooking zone 2 | Left Rear | 210x220 | Induction cooking zone | 2100 Watt | 3000 Watt |
| Cooking zone 3 | Right Rear | 175 | Induction cooking zone | 1400 Watt | 2100 Watt |
| Cooking zone 4 | Right Front | 175 | Induction cooking zone | 1400 Watt | 3100 Watt |
